2008 SCM F 410 Nova Jointer

Manufacturer: SCM Group

Model: F 410 Nova

Year of Manufacture: 2008

Condition: Used – Good Operating Condition

Machine Type: Industrial Jointer / Surface Planer

Machine Description

The SCM F 410 Nova is a heavy-duty industrial jointer designed for precision face-jointing and edge-jointing of solid wood components.

Manufactured in Italy by SCM, the Nova series combines robust cast iron construction, long table support, and precision cutterhead performance to deliver accurate stock preparation in demanding woodworking environments.

The machine features SCM's parallelogram table movement system, ensuring constant table-to-cutterhead alignment for long-term accuracy and smooth operation. Large ribbed cast iron work tables provide excellent rigidity and vibration control for superior finish quality.

Key Features

• 410 mm (16.1") jointing width
• Heavy-duty cast iron construction
• Long cast iron infeed and outfeed tables
• Parallelogram table adjustment system
• Industrial fence assembly
• 4-knife cutterhead
• 5,000 RPM cutterhead speed
• Italian SCM construction

Technical Specifications

Jointing Capacity

• Working Width: 410 mm (16.1")
• Total Table Length: 2610 mm (102.8")
• Infeed Table Length: 1440 mm (56.7")

Cutterhead

• Cutterhead Diameter: 120 mm
• Number of Knives: 4
• Cutterhead Speed: 5,000 RPM

Fence System

• Fence Dimensions: 1200 mm × 190 mm
• Fence Tilt: 90° to 45°

Dust Collection

• Dust Port Diameter: 120 mm
• Recommended Airflow: 1000 m³/h

Main Motor

• Motor Power: 4 kW (5.5 HP)

Machine Construction

• Ribbed cast iron work tables
• Heavy-duty machine frame
• Precision-machined working surfaces
• Industrial cutterhead assembly
• Precision adjustable fence
• Parallelogram table movement for long-term accuracy and stability

Electrical Specifications

• Voltage: 600V
• Phase: 3 Phase
• Frequency: 60 Hz
• Short Circuit Rating (Icc): 5 kA

Condition

Used – Good Operating Condition

The machine remains in good operating condition and is suitable for continued production use. Its long cast iron tables, industrial cutterhead design, and heavy-duty construction make it an excellent stock preparation machine for professional woodworking operations.

Notes

The SCM F 410 Nova is a proven industrial jointer designed for accurate and reliable stock preparation. Featuring a 410 mm working width, 2610 mm total table length, 120 mm four-knife cutterhead, and 5,000 RPM cutterhead speed, this machine delivers the performance and durability expected from SCM's Nova series. All technical specifications listed above are sourced directly from the 2008 SCM F410 Nova factory brochure and verified against the machine identification plate where applicable.
