2011 SCM Minimax S 400 Elite S Sliding Table Saw

Manufacturer: SCM Group

Brand: Minimax

Model: S 400 Elite S

Year of Manufacture: 2011

Condition: Used – Good Operating Condition

Machine Type: Sliding Table Panel Saw

Machine Description

The SCM Minimax S 400 Elite S is a professional European sliding table saw designed for precision panel processing, cabinet production, furniture manufacturing, and architectural millwork applications.

Built in Italy by SCM, the S 400 Elite S combines a heavy-duty cast iron saw unit, precision aluminum sliding carriage, scoring blade system, and large-capacity cutting capability for accurate processing of melamine, plywood, MDF, particleboard, and solid wood materials.

This machine is equipped with a full sliding table, crosscut fence, scoring blade system, and support frame, making it an excellent solution for shops requiring accurate panel sizing and squaring performance.

Key Features

• Professional sliding table panel saw
• Heavy-duty cast iron saw unit
• Precision aluminum sliding carriage
• Independent scoring blade system
• Full crosscut fence and support frame
• Large panel processing capacity
• Tilting main saw blade
• Industrial European construction
• Designed for cabinet and furniture production

Technical Specifications

Main Saw Blade

• Maximum Blade Diameter: 400 mm (15.75")
• Minimum Blade Diameter: 250 mm (9.84")
• Blade Bore Diameter: 30 mm

Scoring Blade

• Diameter: 120 mm (4.72")
• Arbor Diameter: 20 mm
• 20 Tooth Configuration

Cutting Capacity

• Maximum Blade Projection at 90°: 136 mm
• Maximum Blade Projection at 45°: 97 mm

Sliding Table

• Sliding Stroke: 3200 mm (126")
• Precision anodized aluminum carriage
• Large-format panel processing capability

Rip Capacity

• Rip Fence Capacity: 1270 mm (50")

Motor

• Main Saw Motor: 7 HP (5.0 kW)

Cutting System

The machine features a tilting main blade and independent scoring blade configuration for clean cutting of:

• Melamine panels
• MDF
• Particleboard
• Veneered panels
• Plywood
• Solid wood

The scoring blade minimizes chipping and breakout when processing laminated and prefinished materials.

Electrical Specifications

• Voltage: 600V
• Phase: 3 Phase
• Frequency: 60 Hz
• Full Load Current: 10 Amps
• Short Circuit Rating: 5 kA
• Control Voltage: 24V

Condition

Used – Good Operating Condition

The machine remains in good operating condition and is suitable for continued production use. The sliding table, scoring saw, and large panel-cutting capacity make it an excellent machine for precision woodworking applications.

Notes

The SCM Minimax S 400 Elite S is a proven professional sliding table saw offering exceptional panel-cutting accuracy, smooth carriage operation, and robust industrial construction. Featuring a 400 mm blade capacity, 3200 mm sliding stroke, 1270 mm rip capacity, and independent scoring blade system, this machine remains an excellent choice for cabinetmakers, furniture manufacturers, and millwork shops seeking dependable European-built performance.
