Unique 313 Mitre Door Machine

Ideal machine for shaping and drilling cabinet doors

Motors: (2) 5 HP motors for shaping and (2) .33 HP motors for drilling.

Shaper arbor: 1-1/4" counter rotating to minimize "tear out".

Drilling: (2) 10mm collets.

Hold-downs: (2) Pneumatic clamps hold part in position on either side

Capacity: 1" max thickness; 4" max width and unlimited length

Table: Staggered table allow for (2) 1" thick pieces to be machined.

Readouts: Digital setting for dowel positioning

Includes: (1) set of FJ heads
