2001 OMGA Mitre Saw T 50 350

The heaviest duty of all model of OMGA's Precision Mitre Chop Saws (along with the T 53 370). It features a solid cast iron base and head construction. The rotating table rides on roller bearings for maximum smoothness and accuracy. A manual locking device for all the intermediate angles provides a great flexibility to this unit. This precision saw is a multi-purpose machine suitable for use in general carpentry, for cutting moulding, picture frames, furniture components and any application requiring precision cutting.

Features and Specifications

• Cross cut capacity 90°: 6¾''
• Cross cut capacity with head at 45°: 41.8''
• Max. depth 90°: 4⁵⁄₁₆''
• Motor power: 3 HP
• Saw bore: 1'
• Saw diameter: 14''
• Arbor speed: 3400 RPM
• Dust chute: 3⅛''
• Mitre positive stops: 90° - 45°- 30° - 22½° - 15° - 10°
• Table size: 23⅝'' x 17⅛'' x 5³⁄₁₆''
• Approximate shipping dimensions: 26'' x 25'' x 30''
• Approximate shipping weight: 269 lbs (123kg)

Taurus Craco offers - start-up supervision service | turnkey installations | operator training | machine reconditioning | PM service packages –

Please contact TCMI customer service for more information.

---

**Attached PDF may not accurately represent specifications and features of the listed machine**
